Universal 4BBL 1000CFM Throttle Body - Hard Core Gray

Universal 4BBL 1000CFM Throttle Body

LS 95mm TB w/cable drive and taper

Overview
Holley's BILLET LS Throttle Bodies are the BIGGEST BORE (in the 90 to 95mm category) - MOST FEATURE LOADED available. Holley went back to the drawing board and built the ultimate air valve for your LS engine! This all new design boasts a 95 millimeter bore and a low RPM drive friendly taper. Innovative features like Idle Bleed Adjustment, TPS CLOCKER, and closable PCV Passage Valve, make them the ultimate throttle bodies for ease of installation and tuning. Regardless of whether you have a turbo, supercharger, or a big cam engine sucking gulps of air, Holley's throttle bodies are maximized for your application. The barrier protection of the BLACK ANODIZED finish also offers up a modern tech look!

Features:

• Standard square bore mounting pattern for installation on many intake manifolds
• Flows 1000 CFM to handle high horsepower engines
• Exclusive CFD computer modeled air entry area delivers maximum velocity and accelerated air speed
• Integrated TPS, IAC, and Air Temperature Sensor
• Hi Flow IAC passages for large cubic inch engines for idle stability
• Ford Transmission kick down Lever for use with Ford automatic transmissions
• Integrated GM 700R4 transmission kick down location no adapters needed
• All necessary vacuum ports (1) timed spark, (2) 3/8" and (2) 3/16" full manifold vacuum ports
• 1.75" throttle plates mounted to PTFE coated throttle shafts for high flow and a smooth feel
• High quality die cast aluminum for strength and weight reduction
• Hard Core Gray finish

Details:

• Barrels: 4
• CFM: 1000
• Throttle Bore: 1.750 inch

Links
Instruction Sheet
